FEATURES
1, Original design LED solar wall light with PIR motion sensor.
2, Using special optical lens, extremly wide range of lighting.
3, Integrated solar wall light with solar panel and LED chips, the solar panel is with 10° tilt angle, which help the solar panel easier access to solar light, the dust & water can be flow away easily, solar panel will keep good working performace after long time using.
4, Flexible to adjust the angle of solar wall light to get the suitable lighting area.
5, 3CCT tunable, 6500K – 4000K – 3000K, which help you decrease the stock SKUs.
6, Intelligent PIR sensor, 120°detection angle and 8-10M detection area, the light will turn on automatically when <5LUX.
7, Support 2 working modes by button to save energy, under each working mode,long pressing the button for 3S to change the CCT.
8, Use high quality mono-crystalline silicon solar panel, 23% photoelectric conversion rate.
9, Use 18650 lithium batteries, which have a large charge storage capacity during energy conversion, 350 deep charge-discharge cycles, overcharge protection,over-discharge protection, short circuit protection.
10, High quality ABS materials, anti-UV, long life span, color of housing can be customized.
SPECIFICATION
| Product Model: | OC-WL-003A-DWW |
| Power: | 8W |
| CCT: | 6500K+4000K+3000K |
| Lumens: | High light 1450LM; Low light 150LM; Constant lighting 800LM |
| LEDs: | SMD2835*78pcs |
| Solar Panel: | 5V/6Wp, mono-crystalline silicon solar panel |
| Battery: | 18650 lithium batteries, 6000mAh/3.7V |
| Charging Time: | 6 hours |
| Run Time: | Up to 3 nights |
| Induction mode: | Light control+Motion sensor |
| Working Modes: | One key to control 2 working modes |
| PIR Sensor Detection: | 120°detection angle and 8-10M detection area |
| Beam Angle: | 70°x140° |
| IP Degree: | IP65 |
| Housing Color: | Black |
| Housing Material: | ABS+PC |
| Working Temperature: | -20℃~45℃ |
| Storage Temperature: | -20℃~45℃ |
| Dimension: | 288*126.7*181.4mm |
| Weight: | 1.06kg |
OPERATION GUIDE
The default mode of the product is OFF mode. Press the back button to adjust modes when using
the light:
● 1st press for Mode 1 ● 2nd press for Mode 2 ● 3rd press for OFF
Working mode 2
When 2rd pressing the switch, the lamp turns into constant lighting for 6 hours. 6 hours later, the lamp turns into Working Mode 1 automatically, lamps turn off until daytime.
Long pressing the switch for 3 seconds to change the color temperature, the order is 6500K, 4000K and 3000K.
Note:
When the lamp is on, it is in the charging mode during the day, and the light will be off automatically; In the evening, the lamp will turn on automatically.
